Thursday, December 20, 2012

Abandoned Gold Mining Battery

The Karangahake Gorge is found in central North Island of New Zealand, near Coromandel, and now makes a great historic walking track.

The area has a strong connection to gold mining and even in recent times sees a number of companies prospecting and mining the area. The stamping battery remains at the lower end of the gorge are some of the most significant reminders of the time (mining at the batteries occurred roughly from the 1880's to 1950's). The batteries are used to crush the ore from the extensive tunnels mined through the steep local mountainsides.

Monday, December 10, 2012

Hamurana Springs

Hamurana Springs is the deepest natural fresh water spring on the North Island of New Zealand. The spring is approximately 15 metres deep and produces an estimated 4 megalitres of clear water per hour. The spring flows as a stream for one kilometre towards Lake Rotorua.

Wednesday, December 5, 2012

Shootout - The Sequel

This is a follow-up to the Shootout: Pentax Q vs Sony NEX-7 vs Nikon D600 that was reported previously. Following some feedback provided by readers on the methodology used in the previous shootout, a new test has been performed which hopefully improves upon the comparison.

For details regarding the test and cameras involved, please see the previous post:

The following scene was shot under these conditions:
  • Base ISO, which is ISO 100 for the NEX-7 and D600, and ISO 125 for the Pentax Q.
  • Focal length approximately 50mm equivalent.
  • Aperture of F/5.6.
  • Focus achieved using contrast detect autofocus.
  • All shot in RAW format and processed to JPG using Lightroom with no corrections, except:
    • White balance corrected in Lightroom.
    • Exported at 1600 pixels wide.

The full test scene as shot on the Sony NEX-7, 50mm equivalent focal length.

The full test scene is shown in the photo above. I won't bother repeating this for the other two cameras, as you can't see much at this scale.

The following images were cropped to show the same view, and resized to 1600 pixels wide. This represents a 100% crop on the Pentax Q, and approximately 62% crop on the NEX-7 and D600. These cropping percentages apply only when image is viewed full size at 1600 pixels wide.

Pentax Q - Cropped to 100%

Sony NEX-7 - Cropped to 62%

Nikon D600 - Cropped to 62%

This is where we get to the meat of the review. Cropped to this scale, differences between the three cameras are more obvious.

We'll start with an assessment of the Pentax Q, the image is blurry and fuzzy. The colour reproduction is not too bad, but everything lacks clarity. A commenter on the previous Shootout review suggested that the Pentax Q may not have focused properly, so this time I tried to achieve good focus. Again I have not been able to shoot a sharp image under these conditions, so either this is the true performance of the sensor, or the autofocus is very unreliable. I did try autofocus multiple times, and also attempted manual focusing without much success.

The Sony NEX-7 and Nikon D600 do much better, as we'd expect. The small text appears slightly sharper in the D600 image compared to the NEX-7, but this advantage is offset by the obvious false colour being introduced into the image with the extreme details (such as the band of vertical lines at marker 6). Let's go for a closer crop for finer comparison, the following images are 100% crops from the D600 and the NEX-7.

Sony NEX-7 - Cropped to 100%

Nikon D600 - Cropped to 100%

These crops further reinforce the previous comments. The D600 shows sharper text but with the disadvantage of false colour in areas of extreme detail. The NEX-7 on the other hand handles those details in a more pleasing manner. This might suggest a weaker anti-aliasing filter on the D600 compared to the NEX-7. It should be noted that the NEX-7 has a higher pixel density than the D600, which may also be a factor in avoiding false colour arising from fine details.

Dynamic Range

The following image tests the dynamic range of the three cameras. Dynamic range refers to the ability of the camera sensor to capture both details in dark areas at the same time as bright areas (i.e. being able to see inside a cave while retaining correct exposure in brightly sun-lit areas).

A simple method was designed to test this performance measure. The room lighting is now set to a very dim level, and a bright light source is introduced into the image, which in this case is a cellphone screen. The image is exposed correctly for the cellphone, leaving the dark areas completely black. An attempt is then made during postprocessing to recover the shadow details.

Details for this image:

  • Base ISO, which is ISO 100 for the NEX-7 and D600, and ISO 125 for the Pentax Q.
  • Focal length approximately 50mm equivalent.
  • Aperture of F/4.5, shutter speed of 0.3s.
  • Focus achieved using contrast detect autofocus.
  • All shot in RAW format and processed to JPG using Lightroom, with:
    • Shadow Recovery +100
    • Exposure +2.0
    • Colours (white balance) not corrected.
    • Exported at 1600 pixels wide.

Sony NEX-7 - Exposure as Shot
Pentax Q - Exposure +2.0, Shadow Recovery +100

Sony NEX-7 - Exposure +2.0, Shadow Recovery +100

Nikon D600 - Exposure +2.0, Shadow Recovery +100

I won't bother offering too much comment on this test, as the results are very obvious. The Pentax is very noisy and has a purple cast to the shadow areas, no text is readable in the background. The Sony NEX-7 is slightly better, still a fair amount of noise and a green cast. The D600 performs much much better than both other competitors, with fairly good colour reproduction and some minor noise.


Again, we demonstrate that the Pentax Q is not a competitor to APS-C and full frame cameras. Of course, I would never expect it to be able to compete either. This series of tests does push the Pentax Q beyond its limits, and would not represent what the typical usage for this camera should be.

This version 2 shootout is more a comparison of the NEX-7 and the D600, both 24 megapixel cameras with very high expectations, except the D600 is full frame while the NEX-7 is cropped APS-C.

The D600 shows it is king of fine detail, being able to resolve the small text sharper than the NEX-7 does. However, it does also suffer from false colour in the extreme fine details, while the NEX-7 manages to handle it quite nicely.

The dynamic range test shows the D600 outperforming both competitors by several classes and would suggest it would have just as much advantage in real world shooting when both dark and bright areas are present in a single scene.

Sunday, December 2, 2012

Shootout - Pentax Q vs Sony NEX-7 vs Nikon D600

Here we have a shootout comparison between three very different cameras, which are the minuscule Pentax Q, the Sony NEX-7, and the Nikon D600. First up, a brief description of the contenders and what makes them special.

The Pentax Q can be called the smallest interchangeable lens camera, outside of some toy or spy cameras which barely take pictures. It has a correspondingly small sensor size, common to many compact digital cameras.

Pentax Q with Pentax-01 Prime Lens (47mm equivalent)

The Sony NEX-7 is one of the enthusiast level mirrorless cameras available from Sony. Sony produced the first mirrorless APS-C sensor camera with the first generation NEX-3 and NEX-5 cameras, and the NEX-7 improves upon that formula with a digital viewfinder, more control dials, and a powerful 24 megapixel APS-C sensor.

Sony NEX-7 with Sony 18-200mm Zoom Lens

Pentax Q pictured next to a Sony NEX-7. The NEX-7, which is a small camera itself, completely dwarfs the Pentax Q (of course, the giant lens helps too).

The Nikon D600 can claim to be the first affordable full frame DSLR. It has a full frame sensor (equivalent to 35mm film size) in a body that is barely larger than the popular Nikon D7000. It is currently the smallest and lightest full frame DSLR on the market. Also has a 24 megapixel sensor, believed to be sourced from Sony, but it is full frame so the pixel density is lower than the Sony NEX-7.

Smallest Full Frame DSLR ever doesn't mean much when sitting next to a Pentax Q.

For some quick statistics, the Pentax Q with the prime lens attached weighs approximately 240g.

The NEX-7 weighs approximately 350g, and the 18-200mm lens as pictured in this review weighs 524g. To be more fair, the Sony 35mm F/1.8 prime would be the more similar lens to compare with, and that would weigh 155g to give a combined camera + lens weight of 505g.

The Nikon D600 body only weighs 760g, and the Nikon 50mm F/1.4 lens weighs 290g for a total of 1050g.

So in summary, for equivalent approx 50mm shooting with prime lenses, the three combinations come in at 240g for the Pentax Q, 505g for the NEX-7, and 1.05kg for the D600. Or approximately double for each size up.

So how do they compare in photo quality?

For the purposes of this shootout,
  • All three cameras were mounted on the same tripod, shooting at the same target.
  • At a focal length of 50mm equivalent (the Pentax-01 prime is 47mm equivalent, the NEX-7 with zoom lens was set to 32mm, and the D600 has a 50mm lens).
  • At base ISO (ISO 100 for NEX-7 and D600, ISO 125 for Pentax Q).
  • Aperture F/4 for Pentax Q and D600, F/4.5 for NEX-7. Hopefully to balance the playing field for lens quality, but NEX-7 has disadvantage here due to using a zoom lens.
  • Crops taken close to centre of photo to minimise lens quality issues.
  • All images shot in RAW format, processed in Lightroom with no adjustments, and exported to JPG.

Nikon D600

Pentax Q

Sony NEX-7

With the full image resampled down to 1600px width, there's not a lot to separate the three cameras. There's an obvious difference in colour temperature with the Pentax Q, but that's something that's easily fixed in post processing. With all three cameras, the text on the Nikon lens is just readable. The fur on Scooby's paw does seem a little bit sharper on the D600 and NEX-7, but not obviously so.

Crop 1

Next, we have a closer look with a crop around the subject items. This represents an 80% crop of the Pentax Q, and approximately 50% crop on the NEX-7 and D600, when the crops are viewed at 1600 pixels width.

Nikon D600 - 50% crop

Pentax Q - 80% crop

Sony NEX-7 - 50% crop
Since the NEX-7 and D600 are both approximately 24 megapixels resolution, they have the same cropping percentage. This crop represents downsizing the image by around half for those 2 cameras, and 80% crop for the Pentax Q.

At this size, the Pentax Q is obviously inferior, with blurry text on the Nikon lens and the Staedtler pens box. With the slighter brighter exposure on the D600, it does appear to be sharper than the NEX-7, but actual visible level of detail seems to be similar.

There is also a fair bit of false colour noted for the D600 and NEX-7 shots. The text should be black on the Staedtler pens box, but quite a bit of blue is observed in the photo.

Crop 2

We go for a more aggressive crop next, to see if we can identify any further differences in detail. This crop around the Gran Turismo booklet represents a 200% crop on the Pentax Q, and approximately 125% on the NEX-7 and D600.

Nikon D600 - 125% crop

Pentax Q - 200% crop

Sony NEX-7 - 125% crop

The Pentax Q already lost in the last comparison, but for the sake of the comparison we keep going. With this last crop, the Q is completely blurred, with most of the text unreadable. The is ok, as is Polyphony, but that's about it.

Again, the D600 and NEX-7 are very close. The slightly brighter exposure on the D600 does appear to make things look sharper, and the fur on Scooby's paw does seem better defined. In both examples, the white text is easily readable but the red text not really. This seems to be an issue of contrast rather than sharpness though, as the white text is smaller in size. I would predict than in better lighting conditions, the red text should be readable too.


The Nikon D600 has the best sharpness and detail, followed very closely by the Sony NEX-7. In good lighting conditions, there'd be very little to separate the two. This is a huge compliment to the NEX-7, as it is a mirrorless camera with an APS-C size sensor, taking on a full frame DSLR. For future comparisons I'll need to find something with more detail to try and challenge these two cameras.

The Pentax Q obviously can't compete, but it shouldn't have to. It's not a lot worse than the two big boys in the first whole scene size shot, and that's really the level of detail you need when posting on Facebook. The Q is extremely tiny in volume, and only 1/4 the weight of the D600, and 1/2 of the NEX-7 (when the NEX-7 is using a 35mm prime, not the currently pictured monster zoom).

Note that this comparison is focused only on resolution and details. There are many other things that define good image quality, such as dynamic range and colour reproduction, which aren't being tested here. I'll consider looking at these in future reviews.

Update: See Shootout - The Sequal for further tests.

Saturday, December 1, 2012

Wednesday, November 21, 2012

Pentax Q - First Impressions

The Q is a compact size interchangeable lens camera introduced by Pentax in 2011. Many websites are calling it a mirrorless interchangeable lens camera (MILC), which I guess is technically correct as the Q lacks a mirror, but that term usually refers to cameras with DSLR-sized sensors such as the Sony NEX series or the Micro 4/3rds system of cameras from Panasonic or Olympus. Pentax themselves call the Q a Hybrid camera, and this category also includes another camera more similar to those other MILC, being the Pentax K-01 which uses an APS-C sensor.

Pentax Q with Pentax-01 Prime Lens (8.5mm F/1.9, equivalent to approx 47mm on full frame)

The Pentax Q looks like a toy based purely on the size, but it is actually a fully functional camera, and very expensive too with it originally priced at $800 RRP. Pentax have announced a successor to this camera, the Q10, and priced that at a more reasonable but still expensive $600 RRP. This has resulted in discounting of the original Pentax Q, and hence why I have one to play with :)

The Pentax Q compared to a Nikon D600.

The Pentax Q claims to be the smallest interchangeable lens camera, and I'd believe that (not counting some exceptions like spy cameras or obvious toys with no quality). It has a sensor size of 1/2.3", which is a typical size used in many compact cameras. This is approximately 5.5x smaller in area than a full-frame DSLR. The image quality is decent for what the camera is, but should not by any means be compared to DSLR images.

Check out some sample images from the Q below. All images taken with the Pentax-01 Prime lens.

Indoor shot, window lighting. ISO 640 and shutter speed of 1/60. Shot in RAW and converted by Adobe Lightroom. There's a bit of noise, but this is still fairly good performance by a compact camera sensor.

Outdoor shot under bright sunlight. Base ISO at 125. Shot in RAW and converted by Adobe Lightroom. The shadow detail looks pretty good, but the highlights in the sky are totally blown. An attempt to recover highlight detail in Lightroom has resulted in grey sky.

Close-up shot under shade in outdoor light. Good detail, impressive for a compact camera. Check the next image for a 100% crop.

100% crop of the photo above. Decent detail in the individual strands, with a bit of graininess visible in other areas.

100% crop of a Coke bottle at ISO 1000. Lots of noise and grain, but pretty good for 100

This isn't a full review, but more of a first impressions post. I won't conclude whether the Q is a great camera or not, but it definitely is a fun toy. The construction and materials are excellent quality. I wouldn't treat it as a serious camera, and as such don't expect absolutely top image quality.

Additional Info:

Thursday, November 15, 2012

Michael Joseph Savage

Michael Joseph Savage was the first Labour Prime Minister of New Zealand. He is commonly known as the architect of the welfare state and is constantly regarded as one of New Zealand's greatest and revered Prime Ministers. He was given the title New Zealander of the Century by The New Zealand Herald in 1999.

This memorial and water feature, located in the Michael Joseph Savage Memorial Park in Mission Bay, is a well known landmark in Auckland, New Zealand.

Tuesday, November 6, 2012

Gannets Muriwai

Muriwai's gannet colony is a one hour drive from the centre of Auckland. About 1,200 pairs of gannets nest here from August to March each year. Each pair lays one egg and the parents take turns on the nest.

The chicks hatch naked, but within a week they're covered with fluffy down. As they mature, they grow juvenile feathers and begin to exercise their wings in preparation for the one-shot jump off the cliff. Once airborne, the young gannets leave the colony and cross the Tasman Sea to Australia. A few years later, surviving birds return to secure a nest site at the colony.

Saturday, November 3, 2012

Birds in Flight

 Gannets at Muriwai Beach, Auckland, New Zealand.

Muriwai's gannet colony is a one hour drive from the centre of Auckland. About 1,200 pairs of gannets nest here from August to March each year. Each pair lays one egg and the parents take turns on the nest.

The chicks hatch naked, but within a week they're covered with fluffy down. As they mature, they grow juvenile feathers and begin to exercise their wings in preparation for the one-shot jump off the cliff. Once airborne, the young gannets leave the colony and cross the Tasman Sea to Australia. A few years later, surviving birds return to secure a nest site at the colony.

Wednesday, October 24, 2012

Spring Lamb

The smallest cutest young lamb found at Cornwall Park, Auckland, New Zealand.

Saturday, October 20, 2012

Sakura Season

Cherry blossoms in season during Spring time in New Zealand. Cornwall Park, One Tree Hill.

Monday, September 17, 2012

Monday, September 3, 2012

New and Old

Aerial Luxury Apartments built around the heritage listed ES&A Bank Ltd building. The sculptural glass towers house 144 luxury apartments at the heart of Camberwell Junction.

Thursday, August 9, 2012
